NEW HYDMECH GROUP H-40/40

The H-40/40 is a
horizontal band saw
providing accurate 90° metal cutting for heavy-duty applications.
The H-40/40 has a workload capacity of 50,000 lbs. A 5 HP driven hydraulic pump supplies system pressure through three position directional valves controlling all vising, head up/down, blade tension, guide arm, and shuttle movement.
Its PLC control digitally displays blade speed, feed rate, head up limit position, and cut elapsed time, and time remaining.
Featuring a 40″ x 40″ capacity, 20 HP motor, and 3″ blade, the H-40/40 is a reliable choice for all your heavy-duty horizontal metal cutting applications.
Capacity
Rectangular (h x w)
Round
90°
40″ x 40″
40″
Blade Size
3” x 37’
Blade Drive
20 HP VFD
Machine Voltage
480 v (208, 240, 575*)
Blade Speed
45-225 SFM
Machine Weight
42,000 lbs.
Table Height
27”
Dimensions (w x l x h)
215” x 102” x 145”
