| X | 19.7" | 500.38 mm |
| Y | 13.7" | 347.98 mm |
| Z | 10.6" | 269.24 mm |
| Max. Workpiece Dimensions | 28 x 20 x 10.6" | 28 x 20 x 10.6" |
| Max. Workpiece Weight | 1544 Lbs. | 1544 Lbs. |
| Auto Threading (Yes/No) | Yes | Yes |
| Submerged (Yes/No) | Yes | Yes |
| Taper Angle | 15 | 15 |
| Taper Height | 4 | 4 |
| U-V Travels | +/- 2.75" | +/- 2.75" |
| Control Type | Sodick Mark21 Gold | Sodick Mark21 Gold |
| Screen Size | 14 | 14 |
| Program Input Methods | Keyboard, RS-232 | Keyboard, RS-232 |
| Chiller Included | Yes | Yes |
