| X | 21.7" | 551.18 mm |
| Y | 14.6" | 370.84 mm |
| Z | 12" | 304.8 mm |
| Max. Workpiece Dimensions | 33 x 28.7 x 12.2" | 33 x 28.7 x 12.2" |
| Max. Workpiece Weight | 2200 Lbs. | 2200 Lbs. |
| Auto Threading (Yes/No) | Yes | Yes |
| Submerged (Yes/No) | Yes | Yes |
| Taper Angle | 30 | 30 |
| Taper Height | 3.2 | 3.2 |
| U-V Travels | +/- 2.364 | +/- 2.364 |
| Control Type | Fanuc FS-180is-WB | Fanuc FS-180is-WB |
| Screen Size | 12 | 12 |
| Program Input Methods | Keyboard, RS-232, Ethernet | Keyboard, RS-232, Ethernet |
| Chiller Included | Yes | Yes |
| Glass Scales on X & Y Axes | Yes | Yes |
