| X Axis Travel | 28.7" | 728.98 mm |
| Y Axis Travel | 28.7" | 728.98 mm |
| Z Axis Travel | 33.5" | 850.9 mm |
| Spindle Motor | 25 hp | 18.6 kW |
| Spindle Speed | 14,000 RPM | 14,000 RPM |
| ATC Capacity | 180 | 180 |
| Spindle Taper | CAT40 | CAT40 |
| Max Load | 1,100 lb | 499 kg |
| Pallet Size | 19.7" x 19.7" | 19.7" x 19.7" |
| Number of Pallets | 6 | 6 |
| Cut Hours | 9,800 hr. | 9,800 hr. |
Fanuc 31iA CNC Control
6 Carrier Pallet Pool System
Full 4th Axis Rotary Table
Renishaw Optical Sensor Measuring System
Metroi Touch Sensor Measuring System
Through-Spindle Coolant System
CoolJet System 70-36 DF, 8 gpm, fixed 1000 psi
(10) Tombstone City Tombstones & Fixture Plates fitted for 19.7" x 19.7" Pallets
Coordinate System Rotation
Chip Conveyor
