USED BALDOR EM4106T
Overview
Description
Baldor Three Phase Super E General Purpose MotorModel #: EM4016TS/N: Z1107251206HP: 20RPM: 3520Volts: 230/460Amps: 23/46/50Hz: 60Phase: 3Frame: 256TEnclosure Type: TEFC (Totally Enclosed Fan Cooled)Enclosure Material: IronMounting: RigidShaft Diameter: 1.625"Overall Length: 23.28"Rotation: ReversibleNumber of Speeds: 1Service Factor: 1.15Bearings: BallEfficiency: 91.0%Maximum Ambient Temperature: 40° CInsulation Class: FDuty Cycle: ContinuousInverter Duty: YesManufacturer Model #: 09P011Z601Ship Weight: 255 lbs.
Specifications
S/N: Z1107251206
HP: 20
RPM: 3520
Volts: 230/460
Amps: 23/46/50
Hz: 60
Phase: 3
Frame: 256T
Enclosure Material: Iron
Mounting: Rigid
Shaft Diameter: 1.625"
Overall Length: 23.28"
Rotation: Reversible
Number of Speeds: 1
Service Factor: 1.15
Bearings: Ball
Efficiency: 91.0%
Maximum Ambient Temperature: 40° C
Insulation Class: F
Duty Cycle: Continuous
Inverter Duty: Yes
Ship Weight: 255 lbs.
