Power Type: Electric (36-volt battery system)
Capacity: 3,000 lbs @ 24" load center
Drive: 3-wheel, sit-down counterbalanced
Dimensions
Overall Width: approx. 42 in (3.5 ft)
Length to Fork Face: approx. 67 in (5.6 ft)
Height (Mast Lowered): approx. 82–84 in (6.8–7.0 ft)
Overhead Guard Height: approx. 88 in (7.3 ft)
Wheelbase: approx. 44 in (3.6 ft)
Ground Clearance: approx. 4.0 in
Mast and Lift
Typical Mast Type: 2-stage or 3-stage
Maximum Lift Height: varies (usually 188 in with 3-stage mast)
Tilt Forward / Back: 5° / 5°
Lift Speed (Rated Load): ~90–95 ft/min
Lowering Speed (Rated Load): ~90 ft/min
Performance
Travel Speed (Loaded): ~7.0 mph
Travel Speed (Unloaded): ~7.3 mph
Gradeability (Loaded): ~10% typical
Truck Weight (without battery): approx. 6,300–6,400 lbs
With battery installed: up to approx. 8,400 lbs depending on configuration
