NEW Pressmaster GSP-150-6/8

150 Ton 16" Stroke Pressmaster GSP-150-6/8 STRAIGHTEN PRESS

150 TON PRESSMASTER GANTRY STYLE

HYDRAULIC STRAIGHTENING PRESS

MODEL GSP-150T-6/8

RATED CAPACITY, TONNAGE ................. 150

STROKE .................................. 16"

BORE .................................... 11"

RAM SPEED PRESS ......................... 6 IPM

          ADVANCE ....................... 24 IPM

          RETURN ........................ 28 IPM

TABLE SIZE (RIGHT TO LEFT) .............. 72"

TABLE SIZE (FRONT TO BACK)............... 96"

DAYLIGHT ................................ 16.5"

RAM TRAVEL (LEFT TO RIGHT) .............. 59"

MOTOR SPECS ..(230/460/575 AVAILABLE) ... 5 HP / 3 PHASE

WEIGHT ............................. 18,000 LBS.

FLOOR DIMENSIONS ................... 96" L X 78" W X 88" H

STANDARD FEATURES:

- POWERED MOVAEABLE WORKHEAD - FOR OFF CENTER WORK ALLOWS OPERATOR TO POSITION THE CYLINDER FROM LEFT TO RIGHT AND FRONT TO BACK WITH THE TOUCH OF A LEVER.

- CYLINDER ACTIVATION - IS FINGERTIP CONTROLLED, THE MORE THE HAND LEVER IS ENGAGED THE MORE THE RAM MOVEMENT IS ACCELERATED. THIS ALLOWS THE OPERATOR TO CONTROL THE PROPER SPEED FOR THE TASK.

- PRESSURE REGULATOR - LIMITS RAM PRESSURE.

- FLAT RAM NOSE - CAN BE EASILY CHANGED TO ALLOW THE USER TO ADAPT THE PRESS TO A SPECIFIC JOB.

- LOW PRESSURE - HYDRAULIC SYSTEM MAINTAINS LOWER OIL TEMPERATURES, RESULTING IN HIGHER EFFICIENCY AND SAFER OPERATION.

- ALL HYDRAULIC AND MECHANICAL PARTS ARE STANDARD IN THE INDUSTRY, AND AVAILABLE THROUGHOUT NORTH AMERICA.

- OPTIONAL MOVEABLE PEDESTAL C/W HEIGHT ADJUSTMENT FOR EASE AND COMFORT OF OPERATOR

- FULL ONE YEAR WARRANTY.

- NOT A CHEAP IMPORT. MANUFACTURED IN CANADA WITH QUALITY US & CANADIAN COMPONENTS.

OPTIONS:

- HAND HELD REMOTE ................... $9,500

CHECK OUT THIS AMAZING PRODUCT BY CLICKING ON THE BELOW YOUTUBE LINK!!!

https://www.youtube.com/watch?v=XL1Tys3dJsk

FOR MORE INFORMATION: Call Rick at 973-497-7560
