USED Pressmaster 4PP-250

250 Ton 8" Stroke Pressmaster 4PP-250 HYDRAULIC PRESS

250 TON PRESSMASTER HYDRAULIC FOUR-POST PRESS

MODEL HFP4-250

TONS OF FORCE ............................... 250 TONS

RAM SPEED ............(APPROACH)............. 78 IPM

          ............(PRESSING)............. 27 IPM

          ............(RETURN)............... 117 IPM

BORE ........................................ 14"

ROD ......................................... 6"

TABLE ..............(L-R X F-B).............. 48" X 36"

UPPER PLATTEN ......(L-R X F-B).............. 48" X 36"

DAYLIGHT .................................... 26"

STROKE ADJUSTABLE ........................... 15"

FLOOR TO TABLE HEIGHT ....................... 29.75"

OIL RESERVOIR ............................... 100 GALLONS

MOTOR HP @ 1750 RPM ........ 50 HP 230/460/575 VOLTS, 3 PH, 60 Hz.

STANDARD FEATURES:

- PRESSURE GAUGE

- PRESSURE REGULATOR

- ADJUSTABLE STROKE CONTROL

- PRESSURE REVERSAL SWITCH

- ADJUSTABLE SPEED CONTROL

- AIR COOLED INDUSTRIAL OIL COOLER

- RAM TRAVEL IS GUIDED BY 4 PRECISION-GROUND CHROMED RODS

- JOG MODE USED FOR SIMPLIFYING SETUPS

- DUAL CONTROL- YOUR CHOICE OF USING: (1) MOVEABLE PEDESTAL C/W DUAL ELECTRIC PALM BUTTONS @ EMERGENCY STOP OR (2) FOOT PEDAL

- PLC PROGRAMMABLE CONTROL SYSTEM

- AIR COOLED INDUSTRIAL COOLER

- QUALITY LOW SPEED MOTOR

- ALL HYDRAULIC AND MECHANICAL PARTS ARE STANDARD IN THE INDUSTRY, AND AVAILABLE THROUGHOUT NORTH AMERICA

- ONE YEAR WARRANTY ON ALL PARTS

- MFG. IN NORTH AMERICAN FROM US & CANADIAN COMPONENTS

WEIGHT: 15,200

DIMENSIONS: 46" X 96" X 98.75"

AVAILABLE OPTIONS:

- T-SLOTTING ........ (PER LINEAR INCH) ................. $

- ABB HMI PROGRAMMABLE CONTROL REPLACING STANDARD CONTROL ......... $

Example of HMI capabilities:

Product 1

- Ram down to 10"

- Dwell for 3min.

- Ram up 5" inches and wait.

Product 2

- Ram down to 8.5"

- Dwell for 4min.

- Wait 30sec

- Press again for 2min

- Ram up 6" inches and wait.

FOR MORE INFORMATION: Call Rick at 973-497-7560
