NEW Pressmaster HFP-200 MWH

200 Ton 20" Stroke Pressmaster HFP-200 MWH H-FRAME HYDRAULIC PRESS

200 TON PRESSMASTER H-FRAME HYD. PRESS

MODEL HFP-200 MWH         BRAND NEW

RATED CAPACITY, TONNAGE ........................ 200

STROKE ......................................... 20"

BORE ........................................... 12"

RAM SPEED PRESS................................. 6 IPM

RAM SPEED (Inches/minute) ADVANCE............... 24

RAM SPEED (Inches/minute) RETURN ............... 29

DISTANCE BETWEEN POSTS (RIGHT TO LEFT).......... 60"

DISTANCE BETWEEN POSTS (FRONT TO BACK).......... 18"

MAXIMUM DISTANCE FROM BED TO RAM ............... 30.5"

SHIPPING DIMENSIONS

OVERALL HEIGHT ................................. 108"

OVERALL WIDTH .................................. 97"

OVERALL DEPTH .................................. 58"

WEIGHT .................................... 7,600 LBS.

NOT A CHEAP IMPORT -

MANUFACTURED IN CANADA WITH QUALITY US & CANADIAN COMPONENTS

EQUIPPED WITH:

- PRESSURE REGULATOR TO LIMIT RAM PRESSURE

- CYLINDER ACTIVATION IS FINGER TIP CONTROLLED, THE MORE THE HAND

LEVER IS ENGAGED THE MORE THE RAM MOVEMENT INCREASES, ALLOWING

THE OPERATOR TO USE THE PROPER SPEED FOR THE TASK.

- HYDRAULIC POWER LIFT TABLE CONTROLLED WITH A HAND LEVER

- ELECTRIC/HYDRAULIC OPERATION PROVIDES SMOOTH, CONSISTENT PRESSING ACTION

- OPEN SIDES TO FACILITATE WORK ON LONG PIECES

- SELF LOCKING TABLE DESIGN ELIMINATES LATERAL MOVEMENT

- FLAT RAM NOSE TO ALLOW USER TO ADAPT THE PRESS TO A SPECIFIC JOB

- LOW PRESSURE HYDRAULIC SYSTEM MAINTAINS LOWER OIL

TEMPERATURES, RESULTING IN HIGHER EFFICIENCY AND SAFER

OPERATION

- HIGH CAPACITY 20 GALLON HYDRAULIC OIL RESERVOIR

- LOW SPEED, 10 HP, 3 PHASE BALDOR MOTOR-STANDARD VOLTAGES AVAILABLE

- FULL ONE YEAR WARRANTY

- ALL HYDRAULIC AND MECHAINCAL PARTS ARE STANDARD IN THE INDUSTRY AND

READILY AVAIABLE THROUGHT NORTH AMERICA.

AVAILABLE OPTIONS:

- SET OF V-BLOCKS ............................ $1,700

- STOP / START & EMERGENCY STOP .............. $1,000

- FRONT OR BACK SAFETY GUARD .....(PER SIDE).. $1,000

- SIDE SAFETY GUARD ..............(PER SIDE).. $  750

- FOOT PEDAL ................................. $4,500

- ADJ. STROKE CONTROL C/W FOOT PEDAL ......... $6,500

- PRESS PLATE ................................ $4,600

- COMPREHENSIVE SAFETY PACKAGE WITH EMERGENCY STOPS AND

LEXAN GUARDING ............................... $9,500

- HANDHELD REMOTE CONTROL .................... $9,500

FOR MORE INFORMATION: Call Rick at 973-497-7560
