NEW HYDMECH GROUP DM-10P SEMI-AUTOMATIC

Delivery:
TBD
Terms:
Net before Shipment
F.O.B.:
Conway, Arkansas
Warranty:
One year parts
HydMech and SMF and Machine Tools reserves the right to modify this price without liability whatsoever.  Specification and pricing may change with out notice.
Technical Specifications

Capacity
Rectangular (h x w)
Round
Square

90°
9 1/2” x 11”
10”
9”

45° Left
6 1/4” x 4 1/2”
5 3/4”
4 1/2”

30° Right
5” x 4 1/2”
4”
5”

45° Right
8 1/4” x 7”
7 1/4”
7”

Blade Size
1” x 9’ 8”
Coolant Tank Capacity
3.5 Gallons

Blade Drive
2/2.4 HP
Machine Weight
1065 lbs.

Machine Voltage
208*, 240, 480, or 575* v
Table Height
34”

Blade Speed
Two speed – 118/236 SFM
Dimensions (w x l x h)
39” x 67” x 73”
Technical Specifications
Capacity
Rectangular (h x w)
Round
Square
90°
9 1/2” x 11”
10”
9”
45° Left
6 1/4” x 4 1/2”
5 3/4”
4 1/2”
30° Right
5” x 4 1/2”
4”
5”
45° Right
8 1/4” x 7”
7 1/4”
7”
Blade Size
1” x 9’ 8”
Coolant Tank Capacity
3.5 Gallons
Blade Drive
2/2.4 HP
Machine Weight
1065 lbs.
Machine Voltage
208*, 240, 480, or 575* v
Table Height
34”
Blade Speed
Two speed – 118/236 SFM
Dimensions (w x l x h)
39” x 67” x 73”
*Optional Power transformer required
Standard Machine Features
·    Electro-hydraulically operated easy swing, cast saw head
·    Quick release cast-iron vise with dovetail ways
·    Saw Head movement by means of control handle with safety spring loaded trigger switch to start or stop blade or feed mode (depending on selection)
·    A remote foot pedal starts the semi-automatic cycle
·    Rotating table with cut slot that moves in tandem with sawing head
·    Band tension indicator
·    Operator control box houses switches for selecting head feed option; (manual pull-down, powered feed or semi-automatic operation), and semi-automatic operation push buttons for head positioning. Blade speed selection switch, coolant on/off/wash hose and E-Stop button are also found on the control box.
·    Small footprint
·    Robust steel base
·    Easy to read angle scale
·    Adjustable guide arm
·    Pre-set, replaceable carbide guide inserts
·    Mechanical blade tensioning
·    True-direct drive – no belts or pulleys
·    Safety door interlocks
·    Flood coolant
·    Adjustable work stop
·    Replaceable blade brush
Optional Machine Features
·    Mist lubrication
·    R2 Work stop for K110 table
·    Adapter Plate for K110 table
·    208/575 v transformer
·    K110 5’ infeed/out feed roller
SPECIFICATIONS AND CONDITION ARE CORRECT TO THE BEST OF OUR KNOWLEDGE AND ARE SUBJECT TO YOUR VERIFICATION AND CORRECTION. THE CONDITION OF THE MACHINE IS AS IT HAS BEEN REPRESENTED TO US. ALL MACHINES ARE SUBJECT TO PRIOR SALE. EVERY MACHINE, UNLESS OTHERWISE SPECIFIED, IS OFFERED SUBJECT TO OUR GUARANTEE THAT IF FOUND TO BE MECHANICALLY UNSATISFACTORY WITHIN 30 DAYS AFTER SHIPMENT, SAME MY BE RETURNED, FREIGHT PREPAID FOR FULL CREDIT OR REPAIRED AT DEALER’S OPTION. ALL MACHINES RETURNED TO US MUST BE IN AS GOOD A CONDITION AS WHEN SHIPPED.
