| Pallet Size - L | 31.5" | 800.1 mm |
| Pallet Size - W | 31.5" | 800.1 mm |
| Number of Pallets | 2 | 2 |
| Pallet Weight Capacity | 4,850 lb | 2,199.9 kg |
| Pallet Surface to Spindle Center | 1.97" - 41.3" | 1.97" - 41.3" |
| Pallet Center To Spindle Gage Line | 9.8" - 43.3" | 9.8" - 43.3" |
| Workpiece Dimensions | 45.3" (D) x 45.3" (H) | 45.3" (D) x 45.3" (H) |
| X - AxisTravel | 49.2" | 1,249.7 mm |
| Y - Axis Travel | 39.4" | 1,000.8 mm |
| Z - Axis Travel | 33.5" | 850.9 mm |
| B - Axis Travel | 1 Degree | 1 Degree |
| Rapid Traverse Rate - X | 709 in/min. | 18 m/min. |
| Rapid Traverse Rate - Y | 709 ipm | |
| Rapid Traverse Rate - Z | 709 ipm | |
| Cutting Feed Rate | 315 in/min. | 8 m/min. |
| Spindle Speed | 4,500 RPM | 4,500 RPM |
| Spindle Taper | #50 CT | #50 CT |
| Number of Ranges | 3 | 3 |
| Main Motor | 35 hp | 26.1 kW |
| Automatic Tool Changer | 80 | 80 |
| Tool Diameter | 9.6" | 9.6" |
| Tool Length | 23.6" | 599.44 mm |
| Tool Weight | 77 lb | 34.9 kg |
| Tool Change Time | 3.5 sec. | 3.5 sec. |
| Machine Weight | 47,400 lb | 21,500.3 kg |
| Control | CNC (FANUC 18IMB CNC COLOR CONTROL) | CNC (FANUC 18IMB CNC COLOR CONTROL) |
| Dimensions | 160" x 264" | 160" x 264" |
Fanuc 18iMB CNC COLOR Control
Coolant Thru Spindle
Chip Conveyor
Remote MPG
Tool Length Measurement Probe
Rigid Tapping
99 Pairs Tool Offsets
