NEW GOODWAY GS-260
Overview
Description
Unleash the ultimate machining power with the Goodway GS-260 Series ultra performance CNC turning centers, designed to handle the most demanding applications with precision and efficiency. Equipped with advanced industry-leading technology and top-quality components, these CNC turning centers deliver exceptional power, speed, and reliability. Choose from six versatile model configurations with two bed lengths and three spindle sizes to suit your specific needs, making the GS-260 series the ideal choice for diverse applications. Achieve next-level CNC precision and high-performance turning with this ultra-powerful turning center.
Key Features:
• Versatile Multi-Function Operation: Integrates live tooling, C-axis, Y-axis, and sub-spindle capabilities for efficient milling, drilling, and front/back-end turning on one machine, optimizing productivity.
• Advanced 30° Slant-Bed Design: A true 30° slant-bed for improved chip disposal and easier operator access, maximizing workspace efficiency.
• Durable Construction: Stainless steel way covers and molded steel wipers crafted with industrial-strength rubber ensure long-lasting durability and protection.
• Smart Lubrication System: Automatic lubrication delivers precise amounts to slide ways, ball screws, and vital components, with auto-shutoff during idle periods to minimize waste.
Specifications
| Max Swing Diameter | 650 mm | 25.591" |
|---|---|---|
| Max Turning Diameter | 420 mm | 16.535" |
| Max Turning Length | 560 mm | 22.047" |
| Chuck Size | 10" | 254 mm |
| Bar Capacity | 65 mm | 2.5591" |
| Hole Through Spindle | 76 mm | 2.9921" |
| Spindle Nose | A2-8 | A2-8 |
| Spindle Speed | 4,000 RPM | 4,000 RPM |
**For full machine specifications, please refer to the product brochure.
Equipped With
FANUC 0i-TF WITH 8.4 LCD SCREEN
BOX WAYS ON ALL AXIS
CONVOYEUR À COPEAUX
CHIP CART
FOOT SWITCH FOR CHUCK
COOLANT SYSTEM
COOLANR PISTOL
HAND WHEEL WITH STANDAR SCREEN.
HYDRAULIC SYSTEM
AIR BLOW FOR MAIN SPINDLE CHUCK
ELECTRIC CABINET HEATER EXCHANGER
COMMUNICATION: ETHERNet, USB et SD card
EXTRA 8 M CODE
