USED 2014 Mazak QTN 350MSY-II

X2nd Turret Live Tooling: false
X4th Axis: false
X5th Axis: false
Additional Control Options: EIA 3D Comp.

Geometric

Ext-Data I/O

Thread

Sub C-Axis Control

Inverse Time

Auto TLM

Polar Coordinates Input

Comparison Stop

G54.1

Scale Feed Back

Variable 600 Sets

Cylinder

EIA Herical Tap Cycle

EIA Pattern Cycle

Tilted Working Plane

Auto Pecking

Program Memory Expansion

Pitch Error Comp.

Additional Machine Specs: Heavy Duty Holders

Travel Feed (Z-Axis) 63.25"

Travel (Tailstock) 62.38"

Bar Capacity: 4.0
B Axis: false
C Axis: true
Chip Removal: Chip Conveyor
Chuck Size: 12.0
Chuck Type: Hydraulic
Control Make Model: Mazatrol Matrix Nexus Control
Control Options: G-Code, Helical Interpolation, Synchronized Tapping, Rotation and Scaling, EIA/ISO Code Input Function
Coolant Psi: 213.0
Distance Between Centers: 60.0
Electrical: 208V
Live Milling Hp: 10
Live Milling Max Rpm: 6000
Live Milling Thru Spindle Coolant: false
Live Tooling Milling: true
Machine Options: Tool Presetter
Max Cutting Turning Diameter: 16.5
Max Swing Over Bed: 29.5
Max Turning Cutting Length: 62.67
Programmable Tailstock: false
Second Chuck Size: 10.0
Second Spindle Motor: 40
Second Spindle Speed: 3330
Single Turret: false
Single Turret Live Tooling: true
Spindle Bore: 4.25
Spindle Motor: 40
Spindle Nose: CAT#40
Spindle Speed: 4000.0
Sub Spindle: true
Tailstock: true
Tool Positions: 12.0
Total Spindles: 2
Twin Turret: false
X Travel: 10.12
Y Axis: true
Z Travel: 60.0
