Customer-Oriented, Quality Guaranteed, Award-Winning Products
| X | 860 mm | 33.858" |
| Y | 600 mm | 23.622" |
| Z | 610 mm | 24.016" |
| RPM | 8,000 RPM | 8,000 RPM |
| # ATC | 24 | 24 |
| Taper | BT40 | BT40 |
| Table-W | 600 mm | 23.622" |
| Table-L | 1,000 mm | 39.37" |
Working Table Dimension........................ 1,000 x 600 mm
Working Area................................... 860 x 600 mm
Max. Loading Capacity.......................... 600 kg
Max. Travel Range of X/Y/Z-axis................ 860 / 600/ 610 mm
Distance from Spindle Nose to Table Surface.... 120-730 mm
Spindle Speeds................................. STD: 8,000 rpm (belt-driven)
OPT: 10,000/ 12,000/15,000 rpm
Tool Capacity.................................. STD: 24 pcs
OPT: 30 pcs
