NEW GOODWAY GS 2800
Overview
With the latest machine tools technology and precision turning performance, GOODWAY brings you the new GS series high-speed CNC turning center. Using 2 types of beds combined with super rigidity, high-speed turning capability, and compact size provides you with super-efficiency cutting power. The GLS-1500 series equipped with an optional live tooling turret, Y-axis, and sub-spindle can work on turning, milling, and drilling tasks at the same time to increase the output capacity with high-end value to meet your needs of today and tomorrow.
Key Features:
✔ 30°low center gravity slant bed ensures high rigidity of GS-3000 series.
✔ X / Z axes adopt box ways structure and wide span design to ensure best rigidity and precision.
✔ Optional high precision built-in spindle or high power belt-driven spindle to meet any processing request.
✔ X / Z axes are directly driven by a high-performance AC servo motor, rapid feed rate can reach up to 30 m/min.
✔ 12-station servo index turret, adjacent and opposite tool changing only takes up to 0.3 and 0.8 sec.
✔ High-rigidity programmable tailstock or high-performance servo tailstock ensures the best support for the workpiece.
Specs
Equipped With
FANUC OI-TF PLUS WITH 10.4" DYNAMIC GRAPHIC DISPLAY
FANUC MANUAL GUIDE-I
FANUC ABSOLUTE ENCODER AC SERVO DRIVE MOTORS
10" TAIWAN MADE 3 JAWS BIG BORE (78MM BAR CAPACITY) WITH 1 EA HARD AND SOFT JAWS
UPGRADE TO SPINDLE MOTOR 18.5/22KW (BELT TYPE)
CS-AXIS WITH DISK BRAKE ON MAIN SPINDLE
GOODWAY 12 STATION LIVE TOOLING TURRET (4.5KW, ER32)
2 PCS X 0° LIVE TOOL HOLDER ER-32/EC- QUICKFLEX
2 PCS X 90° LIVE TOOL HOLDER ER-32/EC- QUICKFLEX
HYDRAULIC TYPE LP-1 PROGRAMMABLE TAIL STOCK (BUILT IN CENTER: MT4)
AUTO RENISHAW TOOL SETTER (FOR MAIN SPINDLE) HPMA
RIGID TAPPING
SPINDLE ORIENTATION
BOX GUIDWAYS ON ALL AXES
C3 CLASS BALL SCREWS WITH PRETENSION ON ALL AXES
UPGRADED CHIP CONVEYOR HEIGHT 1200MM
AIR BLOW FOR MAIN SPINDLE CHUCK
COOLANT PISTOL WITH PIPE CONTROL BY M CODE
EXTRA 8 M CODE
UPGRADED TO 7 BARS COOLANT PUMP
OIL SKIMMER
COOLANT LEVEL SWITCH
HYDRAULIC SYSTEM
FULLY ENCLOSED SPLASH COVERS
ADVANCE AUTO LUBRICATION SYSTEM
TRI-COLOR SIGNAL TOWER(YELLOW/RED/GREEN)
HIGH INTESITY WORK LIGHT
M CODE AUTOMATIC POWER OFF
FOOT SWITCH FOR CHUCK
RS-232 INTERFACE
ELECTRIC CABINET HEAT EXCHANGER
FOUNDATION AND LEVELING KIT/MAINTENANCE TOOL KIT
OPERATION & MAINTENANCE MANUALS
