The word "Yama" means mountain, or peak, in Japanese. "Seiki" means precision machinery. In the machine tool world, YAMA SEIKI means precision machines with peak performance, quality, and value. Yama Seiki belongs to a group of companies headed by Mr. Edward Yang, who is the President of Goodway Machine Corp. and Awea Mechatronic Co. In cooperation, Goodway and Awea have over 50 years of experience in manufacturing high quality machine tools within their own field of expertise. Both companies are very well recognized worldwide, in over 50 countries, GOODWAY for turning and AWEA for milling.
All Yama Seiki machines are based on the latest Japanese technology and components. Turning centers are manufactured at Goodway and machining centers at Awea under strict ISO 9001 and 14001 regulations. Knowing that the complexity of present and future machining processes require more than just high quality machines, we offer you the Yama Seiki advantage. Obtain faster cycle times with extra power and faster speeds in every Yama Seiki. Save manpower and increase accuracy by eliminating manual part handling with our full range of multi-process machines and fully automated loading systems. Furthermore, all machines are loaded with standard features and accessories that are not available or costly options found on other machines.
Yama Seiki brings you THE ULTIMATE MACHINING POWER® without the ultimate price.
We know searching for the right equipment at the right price is a tough job. Purchasing something that’s unsuitable or unreliable may mean disaster for your company. That is why our team at Yama Seiki and all our authorized distributors are committed in bring you value solutions for your particular turning and milling applications. We also guarantee prompt, friendly service and expert technical after-sales support. Yama Seiki is the ultimate full-service source for your turning and milling needs.
| X-Axis Travel | 2,500 mm | 98.425" |
| Y-Axis Travel | 1,000 mm | 39.37" |
| Z-Axis Travel | 1,000 mm | 39.37" |
| Table Size-X | 2,700 mm | 106.3" |
| Table Size-Y | 1,000 mm | 39.37" |
| Table Load Capacity | 4,000 kg | 8,818.5 lb |
| Spindle Center to Column | 1,100 mm | 43.307" |
| Max Spindle Nose to Table | 1,200 mm | 47.244" |
| Spindle Speed | 6,000 RPM | 6,000 RPM |
| Spindle Taper | CAT50 | CAT50 |
| X/Y Axis Rapid Feed Rate | 15 m/min. | 590.6 in/min. |
| Z-Axis Rapid Feed Rate | 12 m/min. | 472.4 in/min. |
| ATC | 40 | 40 |
| Max. Tool Length | 250 mm | 9.8425" |
| Max. Tool Weight | 15 kg | 33.1 lb |
| CN Control | Fanuc 0i-MF | Fanuc 0i-MF |
| # Axis | 3 | 3 |
FANUC 0I-MF PLUS WITH 10.4” LCD SCREEN
FANUC AICCII (400 BLOCK LOOK-AHEAD) + 2GB DATA SERVER
6,000 RPM GEAR DRIVEN SPINDLE, CAT50 DUAL CONTACT
SPINDLE MOTOR 30/35 HP (FANUC ALPHA 22 MOTOR)
40 TOOL ATC MAGAZINE (ARM TYPE)
COOLANT THROUGH SPINDLE 1000 PSI
AIR THROUGH SPINDLE
CATERPILLAR TYPE CHIP CONVEYOR
CHIP WASH DOWN COOLANT
3-AXIS AUTO LUBRICATION SYSTEM
3-AXIS BALL SCREW PRETENSION
SPINDLE AIR CURTAIN
SPINDLE OIL CHILLER
COOLANT NOZZLES AROUND SPINDLE
FRONT SIDE CHIP AUGER
Y-AXIS CHIP AUGERS
ROOF ENCLOSED SPLASH GUARD
AIR BLOW SYSTEM
CENTRALIZED AUTOMATIC LUBRICATION ( X / Y / Z )
AIR TANK FOR TOOL MAGAZINE
LUBRICANT RECOVERING SYSTEM
OIL SKIMMER
HEAT EXCHANGER FOR ELECTRIC CABINET
COOLANT EQUIPMENT
AIR GUN & COOLANT GUN
ALARM LIGHT & WORK LIGHT
2 EXTRA LED LIGHT INSIDE WORKING AREA
AUTOMATIC POWER-OFF SYSTEM
TOOL BOX & FOUNDATION BOLT KIT
