| X-Axis | 24" | 609.6 mm |
| Y-Axis | 16" | 406.4 mm |
| Z-Axis | 16" | 406.4 mm |
| B-axis | ±120° | ±120° |
| C-axis | 360° | 360° |
| Number of Pallets | 20+1 | 20+1 |
| Working Surface | 7.9" × 7.9" | 7.9" × 7.9" |
| Spindle Motor | 30 hp | 22.4 kW |
| Spindle Speed | 15,000 RPM | 15,000 RPM |
| ATC Capacity | 701 | 701 |
| Table Load Capacity | 198.42 lb |
HAAS CNC Control
20 station pallet pool
Wireless Intuitive Probing
Programmable Coolant Nozzle
Rigid Tapping
Tool Center Point Control
Power-Failure Detection
High Speed Machining
Chip Conveyor
Dynamic Offsets
