PREOWNED HAAS CNC VERTICAL MACHINING CENTER, MODEL #: MINI MILL
| X | 16" | 406.4 mm |
| Y | 12" | 304.8 mm |
| Z | 10" | 254 mm |
| Power | 7.5 hp | 5.6 kW |
| RPM | 6,000 RPM | 6,000 RPM |
| # ATC | 10 | 10 |
| Taper | CAT-40 | CAT-40 |
| Table-W | 12" | 304.8 mm |
| Table-L | 36" | 914.4 mm |
Table Size 36" x 12"
# of Axis 3
X-Travel 16 inches
Y-Travel 12 inches
X-Travel 10 inches
Spindle Nose to Table (Min.) 4 inches
Spindle Nose to Table (Max.) 14 inches
Spindle Speeds 6,000 RPM
Spindle Taper CAT # 40
Tool Capacity 10 ATC
Max. Load on Table 500 pounds
Weight 4000 pounds
