| Table-W | 12" | 304.8 mm |
| Table-L | 54" | 1,371.6 mm |
| Travel-Long | 36" | 914.4 mm |
| Travel-Cross | 16" | 406.4 mm |
| Power | 5 hp | 3.7 kW |
| RPM | 3,600 RPM | 3,600 RPM |
| Taper | NT40 | NT40 |
| Dimensions | 75" x 97" x 91" | 75" x 97" x 91" |
| Weight | 3, 310 lbs | 3, 310 lbs |
Specifications (subject to buyer verification):
Type: Variable
X/Y/Z Travel 36" x 16" x 16"
Table Size: 12" x 54"
Maximum Table Load: 350kgs
T-Slots (No x Width x Pitch): 3 x 63 x 16mm
Head Swivel: R,L 90 Deg F,B 45 Deg
Taper: NT40
Spindle Speed: Var 60 - 3,600 RPM
Spindle Motor: 5 HP
Machine Size (cm): 190cm x 245cm x 230cm
Machiene Net Weight: 1,500kgs
Equipped With (subject to buyer verification):
Rapid Traverse motor for Z-axis
Chip Tray
Coolant system
Auto lubrication
Turcite B on X/Y axis
Hardened & Ground ways
Hardened & Ground table surface, box ways
Optional Equipment (available at additional cost):
LED-L81/24V9W Light (W/O Plug), extra = Included
Power feeds (CE500P-X+Y) on X/Y Axis Set = Included
FAGOR 3-Axis DRO, extra = Included
Ball Screws on X & Y Axis = Included
Air Power Draw Bar PD-150 = Included
