USED DODGE SK X 1-1/4-KW

Bore Type: Finished w/ Keyway
Keyway Size: 1/4 x 1/8 in
Bore Diameter: 1.2500 in - 1-1/4 in
Flange Outside Diameter: 3.8750 in - 3-7/8 in
Flange Thickness: 0.5000 in - 1/2 in
Length Through Bore: 1.8750 in - 1-7/8 in
Material: Steel
Torque Capacity: 7000.0000 in - 7000 in
Mounting Type: Conventional or Reverse
Screw Torque: 180 in
Maximum Hub Outside Diameter: 4-3/4 (Class 30 Iron) in, 4-1/2 (Steel) in
Barrel Diameter: 2.81 in
Barrel Length: 1.38 in
Bolt Circle Diameter: 3.31 in
Number of Bolt Holes: 3
Screw Thread Size: 5/16-18 in
Screw Length: 2 in
