Used vertical machining center with 5-axis capability. Features Fanuc 31i control, CAT 50 taper, 120"x33"x27.5" XYZ travel, 12,000 RPM, 75 hp, and a 30 tool ATC. Table size of 126"x33.5" supports up to 6,600 lbs.
| X | 120" | 3,048 mm |
| Y | 33" | 838.2 mm |
| Z | 27.5" | 698.5 mm |
| Power | 75 hp | 55.9 kW |
| RPM | 12,000 RPM | 12,000 RPM |
| # ATC | 30 | 30 |
| Taper | CAT 50 | CAT 50 |
| Control | CNC (Fanuc 31i) | CNC (Fanuc 31i) |
Table Size 126" x 33.5"
Table Load Capacity 6,600 Lbs
Control Fanuc 31i
Chip Removal Chip Conveyor
Additional Axis 5th Axis Ready
A/B-Axis Rotation + 35 Degree
Coolant Standard Coolant System
