SPECIFICATIONS:
Pack:
Width: Min. 150mm
Height: 150 mm – 1.200 mm
Face: Min. 150mm
Index Drive: Electrical
Strap:
Feed Speed: 2-3 m/sec – depending on model selected
Tension: up to 22.000 N
Joint Strength: up to 90 % (depending on head type)
Joint Strength: 19 – 32 mm Steel / PET
Dispenser: 450 / 900 kg coils
Control Voltage: 24 V DC
Consumption: up to 40 KVA (weld) 1.200 L/cycle (M410) Depending on Strapping Head
Machine Weight: 4000 to 5000 Kg
Features and Benefits:
High production throughput for continuous pipe production and stacking operations
Maximum machine up-time due to reliable Signode strapping heads
Improved package stability- high consistent strap tension onto load
Lower cost of ownership with easy service & maintenance
Avoiding pilferage due to high strap tension
Options:
Indexing on floor or on overhead gantry depending on plant layout
Label applicator magazine and printer
Super-jumbo coil (450 and 900 Kg) strap dispenser Strap coil loading crane manual/electrical
Safety Guarding Package
Other PLC Control systems available
