| Dimensions | 10′ x 4′ x 8′ | 10′ x 4′ x 8′ |
| Weight | 7,000 Lbs. | 7,000 Lbs. |
SPECIFICATIONS:
Capacity: 12″ x .024″ x .077″ Mild Steel
Maximum Yield Strength: 40,000 PSI
Maximum Width: 12″
Machine Tag Specifications: Max. Thickness: .077″, Min. Thickness: .024″
Number of Work Rolls: 23
Work Roll Diameter: .875″
Number of Adjustable Backup Roll Flights: 3
Pass Line Height: 37″ (without Sub-Base)
Line Speed: 60-360 FPM
Line Direction: Right to Left
EQUIPPED WITH:
Powered Pinch Rolls
5 HP GE Motor
5 HP GE Speed Variator
CONDITION: Excellent, Has been tested.
OVERALL DIMENSIONS: 10′ x 4′ x 8′
APPROXIMATE WEIGHT: 7,000 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
EQUIPPED WITH: Powered Pinch Rolls 5 HP GE Motor 5 HP GE Speed Variator
