| Dimensions | 5-1/2′ x 2-1/2′ x 4′ | 5-1/2′ x 2-1/2′ x 4′ |
| Weight | 2,500 Lbs. | 2,500 Lbs. |
SPECIFICATIONS:
Idle Straightener Rolls
Maximum Strip Width: 12"
Minimum Strip Width: 9"
Pass Line of Strip: 42-1/2"
Line Direction: Right to Left
EQUIPPED WITH:
2 Entry Pinch Rolls: 15-3/4" L x 2" Diameter
1st Set Leveling Rolls, 5 Over 6, 16-1/4" x 2-1/8" Diameter
2nd Set Leveling Rolls, 3 Over 2, 16-1/4" x 2-1/8" Diameter
Entry & Exit Adjustable Strip Guide with Wear Plates
Manual Adjustment of Top Rolls
Encoder Stand
OVERALL DIMENSIONS: 5-1/2′ x 2-1/2′ x 4′
APPROXIMATE WEIGHT: 2,500 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
EQUIPPED WITH: 2 Entry Pinch Rolls: 15-3/4" L x 2" Diameter 1st Set Leveling Rolls, 5 Over 6, 16-1/4" x 2-1/8" Diameter 2nd Set Leveling Rolls, 3 Over 2, 16-1/4" x 2-1/8" Diameter Entry & Exit Adjustable Strip Guide with Wear Plates Manual Adjustment of Top Rolls Encoder Stand
