| Dimensions | 10′ x 6’6″ x 8′ | 10′ x 6’6″ x 8′ |
| Weight | 9,500 Lbs. | 9,500 Lbs. |
SPECIFICATIONS:
Maximum Strip Width: 24″ (609 mm)
Maximum Strip Thickness: .187″ (4.75 mm)
EQUIPPED WITH:
Peeler Arm w/Hydraulic Extension and Retraction
Coil Peeler Arm w/Hydraulic Hold Down Roll
Entry Guide Plates w/Measurements
Hydraulic Shear Blade Downstroke: 6″
Stationary Lower Blade
Shear Force: 12 Tons
Shear Blades are 26″ Long w/2 Degree Angle
Hydraulic Pinch Rolls: 32″ Wide x 4″ Diameter
NOTE: Missing Hydraulic Unit.
OVERALL DIMENSIONS: 10′ x 6’6″ x 8′
APPROXIMATE WEIGHT: 9,500 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
EQUIPPED WITH: Peeler Arm w/Hydraulic Extension and Retraction Coil Peeler Arm w/Hydraulic Hold Down Roll Entry Guide Plates w/Measurements Hydraulic Shear Blade Downstroke: 6″ Stationary Lower Blade Shear Force: 12 Tons Shear Blades are 26″ Long w/2 Degree Angle Hydraulic Pinch Rolls: 32″ Wide x 4″ Diameter
