| Dimensions | 4′ x 4′ x 5′ | 4′ x 4′ x 5′ |
| Weight | 2,800 Lbs. | 2,800 Lbs. |
SPECIFICATIONS:
Capacity: 8 Tons
Die Space: 3″ – 7″
Stroke: 2-1/2″
Flywheel RPM: 300
Slide Adjustment: 2″
Top Die Rail: 3-3/8″ x 14″
Bottom Die Rail: 4-15/16″ x 20″
Post Diameter: 1-3/4″
Distance Between Posts: 11″ (Left – Right), 5″ (Front – Back)
EQUIPPED WITH:
WICHITA Clutch
5 HP Motor, 230/460/3/60
Push Buttons
OVERALL DIMENSIONS: 4′ x 4′ x 5′
APPROXIMATE WEIGHT: 2,800 Lbs.
EQUIPPED WITH: WICHITA Clutch 5 HP Motor, 230/460/3/60 Push Buttons
