| Dimensions | 18′ x 4′ x 6-1/2′ | 18′ x 4′ x 6-1/2′ |
| Weight | 8,000 Lbs. | 8,000 Lbs. |
SPECIFICATIONS:
Maximum Tube Diameter: 7" (177 mm)
Minimum Tube Diameter: 3/4" (19.0 mm)
Maximum Wall Thickness: 1-1/2" (38.1 mm)
Stock Feed Rate: 160 FPM (49 m/Min)
16 Spindle Speeds: 59 – 912 RPM
EQUIPPED WITH:
7.5 HP Main Drive Motor: AC, 1150 RPM
1 HP Feed & Coolant Pump Motors, 1200 RPM
Double Slide
Feeder: Maximum Tube Length 32′
Electrical Panel
Spare parts and extra collets for different sizes.
CONDITION: Good, as taken from service.
OVERALL DIMENSIONS: 18′ x 4′ x 6-1/2′
APPROXIMATE WEIGHT: 8,000 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
EQUIPPED WITH: 7.5 HP Main Drive Motor: AC, 1150 RPM 1 HP Feed & Coolant Pump Motors, 1200 RPM Double Slide Feeder: Maximum Tube Length 32′ Electrical Panel Spare parts and extra collets for different sizes.
