| Dimensions | 9′ x 3′ x 4′ | 9′ x 3′ x 4′ |
| Weight | 3,500 Lbs. | 3,500 Lbs. |
SPECIFICATIONS:
Maximum Tube Length: 36" (914 mm)
Minimum Tube Length: 6" (152 mm)
Maximum Tube Diameter: 1" (25.4 mm)
Minimum Tube Diameter: 3/8" (9.52 mm)
Maximum Bar Diameter: 2.4" (60.9 mm)
Minimum Bar Diameter: 3/8" (9.52 mm)
Profile Section: 3/8" x 3/8" to 2" x 2" (9.52 mm x 9.52 mm to 50.8 mm x 50.8 mm)
Output: 3,500 Maximum Pieces per Hour
Brush Length: 8" (203 mm)
Brush O.D.: 10" or 12" (254 mm or 304 mm)
Motors: (2) 2.2 Kw, 380 / 440 / 3 / 50
EQUIPPED WITH:
Electrical Panel
Push Buttons
OVERALL DIMENSIONS: 9′ x 3′ x 4′
APPROXIMATE WEIGHT: 3,500 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
EQUIPPED WITH: Electrical Panel Push Buttons
