| Dimensions | 14′ x 6′ x 5′ | 14′ x 6′ x 5′ |
| Weight | 2,900 Lbs. | 2,900 Lbs. |
SPECIFICATIONS:
Maximum Tube Length: 96" (2,438 mm)
Minimum Tube Length: 6" (152 mm)
Maximum Tube Diameter: 3" (76.2 mm)
Minimum Tube Diameter: 3/8" (9.52 mm)
Maximum Bar Diameter: 2.4" (60.9 mm)
Minimum Bar Diameter: 3/8" (9.52 mm)
Profile Section: 3/8" x 3/8" (9.52 mm x 9.52 mm) to 2" x 2" (50.8 mm x 50.8 mm)
Output: 3,500 Maximum Pieces per Hour
Brush Length: 18" (457 mm)
Brush Outside Diameter: 10" (254 mm)
EQUIPPED WITH:
Electrical Panel
Push Buttons
Casters
(2) 7.5 HP Motors: 230 / 460 / 60, 1735 RPM
OVERALL DIMENSIONS: 14′ x 6′ x 5′
APPROXIMATE WEIGHT: 2,900 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
EQUIPPED WITH: Electrical Panel Push Buttons Casters (2) 7.5 HP Motors: 230 / 460 / 60, 1735 RPM
