| Dimensions | 17′ 6" x 6′ 6" x 5′ | 17′ 6" x 6′ 6" x 5′ |
| Weight | 3,000 Lbs. | 3,000 Lbs. |
SPECIFICATIONS:
Maximum Tube Length: 120" (3,048 mm)
Minimum Tube Length: 6" (152 mm)
Maximum Tube Diameter: 3" (76.2 mm)
Minimum Tube Diameter: 3/8" (9.52 mm)
Maximum Bar Diameter: 2.4" (60.9 mm)
Minimum Bar Diameter: 3/8" (9.52 mm)
Profile Section: 3/8" x 3/8" to 2" x 2" (9.52 mm x 9.52 mm to 50.8 mm x 50.8 mm)
Output: 3,500 Maximum Pieces per Hour
Brush Length: 18" (457 mm)
Brush O.D.: 10" or 12" (254 mm or 304 mm)
Motors: (2) 5.5 Kw, 380 / 440 / 3 / 50
NOTE: Missing Electrical Panel
OVERALL DIMENSIONS: 17′ 6" x 6′ 6" x 5′
APPROXIMATE WEIGHT: 3,000 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
