| Dimensions | 22′ x 6′ x 5’6" | 22′ x 6′ x 5’6" |
| Weight | 2,600 Lbs. | 2,600 Lbs. |
SPECIFICATIONS:
Maximum Tube Length: 144" (3,657 mm)
Minimum Tube Length: 6" (152 mm)
Maximum Tube Diameter: 3" (76.2 mm)
Minimum Tube Diameter: 3/8" (9.52 mm)
Maximum Bar Diameter: 2.4" (60.9 mm)
Minimum Bar Diameter: 3/8" (9.52 mm)
Profile Section: 3/8" x 3/8" to 2" x 2" (9.52 mm x 9.52 mm to 50.8 mm x 50.8 mm)
Output: 3,500 Maximum Pieces per Hour
Brush Length: 18" (457 mm)
Brush O.D.: 10" or 12" (254 mm or 304 mm)
Motors: (2) 16 Kw, 380 / 440 / 3 / 50
EQUIPPED WITH:
Electrical Panel
Push Buttons
OVERALL DIMENSIONS: 22′ x 6′ x 5’6"
APPROXIMATE WEIGHT: 2,600 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
EQUIPPED WITH: Electrical Panel Push Buttons
