| Dimensions | 30′ x 5′ x 5′ | 30′ x 5′ x 5′ |
| Weight | 2,600 Lbs. | 2,600 Lbs. |
SPECIFICATIONS:
Maximum Tube Length: 168" (4,267 mm)
Minimum Tube Length: 6" (152 mm)
Maximum Tube Diameter: 3" (76.2 mm)
Minimum Tube Diameter: 3/8" (9.52 mm)
Maximum Bar Diameter: 2.4" (60.9 mm)
Minimum Bar Diameter: 3/8" (9.52 mm)
Profile Section: 3/8" x 3/8" to 2" x 2" (10 mm x 10 mm to 50 mm x 50 mm)
Output: 3,500 Maximum Pieces per Hour
Brush Length: 18" (450 mm)
Brush O.D.: 10" or 12" (250 mm or 300 mm)
Motors: (2) 4.0 Kw, 380 / 440 / 3 / 50
OVERALL DIMENSIONS: 30′ x 5′ x 5′
APPROXIMATE WEIGHT: 2,600 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
