SPECIFICATIONS:
Maximum Coil Weight: 20,000 Lbs.
Maximum Coil Width: 48″
Maximum Coil O.D. 72″
Mandrel Expansion Range: 18-1/2″ – 24-1/2″
Cantilevered Mandrel
Motorized Uncoiler (brake not included)
Pushbutton control panel not included (controls can be configured to customer requirements)
EQUIPPED WITH:
Coil Car
Hold Down Roll
Hydraulic Loop Arm Control with Chain Drive Spindle
LOCATION: Universal Warehouse, Perrysburg, Ohio
EQUIPPED WITH: Coil Car Hold Down Roll Hydraulic Loop Arm Control with Chain Drive Spindle
