| Dimensions | 9′ L x 6′ W x 4′ High | 9′ L x 6′ W x 4′ High |
| Weight | 2,000 Lbs. | 2,000 Lbs. |
SPECIFICATIONS:
Maximum Coil Weight: 8,000 Lbs.
Platform Size: 72″
Maximum Coil O.D.: 60″
Maximum Stack Height: 37″
Strip Width: 1/2″ – 6″
Electric: 110/1/60
Stock Thickness Capacity: .062″
EQUIPPED WITH:
Powered Coil Retention Arm
Clockwise/Counter Clockwise Payout Direction
DC Motor Speed Control
Roller Stand Strip Support
Loop Control Arm
OVERALL DIMENSIONS: 9′ L x 6′ W x 4′ High
APPROXIMATE WEIGHT: 2,000 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
EQUIPPED WITH: Powered Coil Retention Arm Clockwise/Counter Clockwise Payout Direction DC Motor Speed Control Roller Stand Strip Support Loop Control Arm
