| Dimensions | 6-1/2′ x 6′ x 6-1/2′ | 6-1/2′ x 6′ x 6-1/2′ |
| Weight | 1,500 Lbs | 1,500 Lbs |
SPECIFICATIONS:
Maximum Coil Weight: 5,000 Lb.
Maximum Coil O.D.: 50"
Maximum Strip Width: 8"
Maximum Material Thickness: .050"
Maximum Rated Speed: 20 RPM
Maximum Coil Height: 30"
EQUIPPED WITH:
RapidAir "Pivot Arm"
1 HP Drive, 115 V / 1 / 60
NOTE: Tested 08/18/17
OVERALL DIMENSIONS: 6-1/2′ x 6′ x 6-1/2′
APPROXIMATE WEIGHT: 1,500 Lbs
LOCATION: Universal Warehouse, Perrysburg, Ohio
EQUIPPED WITH: RapidAir "Pivot Arm" 1 HP Drive, 115 V / 1 / 60
