| Dimensions | 18′ x 4′ x 4′ | 18′ x 4′ x 4′ |
| Weight | 15,000 Lbs. | 15,000 Lbs. |
SPECIFICATIONS:
Number of Stands: 15
Line Direction: Right to Left
Roll Shaft Diameter: 1-1/2"
Roll Space: 10"
Horizontal Centers: 12"
Vertical Centers: 4-1/2" – 6-1/2"
Base to Lower Shaft: 6"
Line Speed: 100 FPM, Max. Gear In No Load.
EQUIPPED WITH:
20 HP Motor
Coolant Pump
Push Button Console
Control Panel with ETON DYNAMIC Drive
OVERALL DIMENSIONS: 18′ x 4′ x 4′
APPROXIMATE WEIGHT: 15,000 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
EQUIPPED WITH: 20 HP Motor Coolant Pump Push Button Console Control Panel with ETON DYNAMIC Drive
