SPECIFICATIONS:
Driven Stands: 14
Spindle Diameter: 2-1/2"
Roll Space: 42"
Vertical Adjustment: 4"- 7-1/4"
Horizontal Centers: 13-1/2"
Center Line of Lower Spindle to Base: 6"
Line Direction: Left to Right
EQUIPPED WITH:
CONE Double Input Single Output Gear Boxes
D30A903 4
15:1 Ratio
1150 RPM
Entry Guide
Motor: 20 HP GENERAL ELECTRIC, 230 / 460 – 1770 RPM 47.4 / 23 / 7 Amps
Tooling: Currently Tooled
CONDITION: Excellent
MACHINERY WEIGHTS & DIMENSIONS:
Rollformer: 20′ x 6′ x 6′, 15,000 Lbs.
Gearbox Base (1): 12′ x 2′ x 6′, 3,000 Lbs.
Gearbox Base (2): 9′ x 1′ x 6′, 2,500 Lbs.
Crate of Drive Shafts: 2′ 6" x 2′ 6" x 2′ 6", 350 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
EQUIPPED WITH: CONE Double Input Single Output Gear Boxes D30A903 4 15:1 Ratio 1150 RPM Entry Guide Motor: 20 HP GENERAL ELECTRIC, 230 / 460 – 1770 RPM 47.4 / 23 / 7 Amps Tooling: Currently Tooled
