12 Stand x 1-1/4″ x 4-1/8″ ENGEL Rollformer

SPECIFICATIONS:
Material Thickness: 19 – 22 Gauge
Number of Stands: 12
Roll Shaft Diameter: 1-1/4"
Shaft Keyway Size: 1/4"
Roll Space: 4-1/8" & 4-3/8"
Horizontal Centers: 6"
Vertical Centers: 4"
Base Top to Center Lower Shaft: 4-3/4"
Line Direction: Right to Left
Gear Driven, Unequal Geared
EQUIPPED WITH:
Double Strip Guide
Motor: 5 HP, 230 / 460 / 3 / 60 – 1725 RPM
TOOLING: Roll Tooling for (2) Different Shapes
CONDITION: Very Good
OVERALL DIMENSIONS: 9-1/2′ x 3′ x 39"
APPROXIMATE WEIGHT: 4,000 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio

EQUIPPED WITH: Double Strip Guide Motor: 5 HP, 230 / 460 / 3 / 60 – 1725 RPM
