| Dimensions | 13′ x 4′ x 5′ | 13′ x 4′ x 5′ |
| Weight | 11,500 Lbs. | 11,500 Lbs. |
SPECIFICATIONS:
Number of Passes: 10
Line Direction: Left to Right
Spindle Diameter: 1-3/4″
Roll Space: 12″
Horizontal Center: 12″
Vertical Adjustment: 5″ – 6″
Base Top to Center Lower Spindle: 6″
Spindle Key Size: 3/8″ Sq.
EQUIPPED WITH:
Entry Guide
Straightener
NOTE:
Missing 5 Outboard Stands
OVERALL DIMENSIONS: 13′ x 4′ x 5′
APPROXIMATE WEIGHT: 11,500 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
EQUIPPED WITH: Entry Guide Straightener
