| Dimensions | 17′ x 5′ x 5′ | 17′ x 5′ x 5′ |
| Weight | 6,500 Lbs. | 6,500 Lbs. |
SPECIFICATIONS:
Number of Passes: 10
Line Direction: Right to Left
Roll Shaft Diameter: 1-1/2"
Roll Space: 8"
Horizontal Centers: 18"
Vertical Adjustment: 4" – 9"
Base Top to Center Lower Shaft: 7"
Line Speed: 100 FPM
Shaft Keyway Size: 3/8"
Gearing: Equal Geared
EQUIPPED WITH:
Stock Guide
Push Buttons
Electrical Cabinet
25 HP Motor & Belt Drive, AC 460 / 3 / 60 – 1750 RPM
NOTE:
Missing 5 Outboard Stands
OVERALL DIMENSIONS: 17′ x 5′ x 5′
APPROXIMATE WEIGHT: 6,500 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
EQUIPPED WITH: Stock Guide Push Buttons Electrical Cabinet 25 HP Motor & Belt Drive, AC 460 / 3 / 60 – 1750 RPM
