| Dimensions | 9′ 10" x 6′ 5" x 9′ 5" | 9′ 10" x 6′ 5" x 9′ 5" |
| Weight | 3,000 Lbs. | 3,000 Lbs. |
SPECIFICATIONS:
Number of Stands: 10
Line Direction: Right to Left
Roll Shaft Diameter: 1-3/8"
Roll Space: 12" Center, 3-1/2" Outside
Horizontal Centers: 8"
Vertical Center: 5"
Base Top to Center Lower Shaft: 7-1/2"
Shaft Keyway Size: 1/4"
Gear Driven, Unequal Geared
EQUIPPED WITH:
Strip Guide
Motor: Sterling Electric 10 HP, 208, 220 / 440 / 3 / 60 – 1740 RPM A/C
TOOLING: Roll Tooling On One Side
CONDITION: Good
OVERALL DIMENSIONS: 9′ 10" x 6′ 5" x 9′ 5"
APPROXIMATE WEIGHT: 3,000 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
EQUIPPED WITH: Strip Guide Motor: Sterling Electric 10 HP, 208, 220 / 440 / 3 / 60 – 1740 RPM A/C
