| Dimensions | 7′ 3" x 3′ x 3′ 4" | 7′ 3" x 3′ x 3′ 4" |
| Weight | 2,000 Lb. | 2,000 Lb. |
SPECIFICATIONS:
Number of Stands: 10
Line Direction: Right to Left
Roll Shaft Diameter: 1-1/8"
Roll Space: 6" Center, 2-1/2" Outsides
Horizontal Centers: 6"
Vertical Center: 3-1/2"
Base to Lower Shaft: 3-1/4"
Shaft Keyway Size: 1/4"
Capacity: 20 Gauge
Gear Driven, Equal Geared
EQUIPPED WITH:
Strip Guide
Motor: 5 HP, 208, 220/440/3/60 – 1730 RPM
CONDITION: Good
OVERALL DIMENSIONS: 7′ 3" x 3′ x 3′ 4"
APPROXIMATE WEIGHT: 2,000 Lb.
LOCATION: Universal Warehouse, Perrysburg, Ohio
EQUIPPED WITH: Strip Guide Motor: 5 HP, 208, 220/440/3/60 – 1730 RPM
