| Dimensions | 8′ x 8′ x 4′ | 8′ x 8′ x 4′ |
| Weight | 4,000 Lbs. | 4,000 Lbs. |
SPECIFICATIONS:
Maximum Strip Width: 36"
Minimum Strip Width: 8"
Shaft Diameter: 1-1/4"
Shaft Length: 3"
Roll Space:
Horizontal Centers: 5"
Vertical Centers: 3"
Line Direction: Right to Left
Floor to Strip Height: 40"
EQUIPPED WITH:
Adjustable Stock Guides, Entry & Exit
(1) Material Center Support
Width Dial Indicator
Chain & Gear Driven
Pendant Control
Main Motor: 7.5 HP, 480 / 3 / 60
OVERALL DIMENSIONS: 8′ x 8′ x 4′
APPROXIMATE WEIGHT: 4,000 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
EQUIPPED WITH: Adjustable Stock Guides, Entry & Exit (1) Material Center Support Width Dial Indicator Chain & Gear Driven Pendant Control Main Motor: 7.5 HP, 480 / 3 / 60
