USED MCKAY S.O. #4414

SPECIFICATIONS:
Maximum Tube Diameter: 1-1/2" (38.1 mm)
Minimum Tube Diameter: 1/2" (12.7 mm)
Maximum Wall Thickness: .050" (1.27 mm)
Minimum Wall Thickness: .020" (.508 mm)
Maximum D/T Ratio: 60:1
Minimum D/T Ratio: 10:1
Maximum Material Yield: 50,000 PSI
Maximum Mill Speed: 150 FPM (46 MPM) Max Gear In Speed, No Load
Roll Space:
Forming: 10-1/2″
Sizing: 10″
Vertical Adjustment: 4″ – 7″
Center Lower Spindle to Base: 6″
Driven Spindle Diameter: 1-3/4″
Hand of Operation: Right to Left
FORMING MILL
(1) Pinch Roll
(1) Entry Guide Unit with Edge Trimming
(3) Driven Breakdown Stands
(3) Driven Fin Stands
(6) Idle Side Roll Units
(1) 20 HP D.C. Motor, 1750 RPM
WELDING SECTION:
(1) MCKAY ERW Welder, 75 KVA
(1) Seam Guide Unit
(1) Weld Pressure Unit, 2-Roll
COOLANT SECTION:
(1) 5′ Coolant Zone
SIZING MILL:
(3) Driven Sizing Stands, 2″ Shaft Diameter
(3) Idle Side Roll Units
(1) Straightener
(1) 20 HP D.C., 1750 RPM
ELECTRICAL:
SHERER ELECTRICS Control Panel
TOOLING: 1.05″ Round On Mill
CONDITION: Good, Electrics Should be Replaced
OVERALL DIMENSIONS: Multiple Pieces, 1 Truckload
APPROXIMATE WEIGHT: 45,000 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
