NEW EDWARDS ED9-IW65-1P230-A

Voltage: 230 volts
Phase: Single-phase
Tons: 65 ton
Stock Number: ED9-IW65-1P230-A
Amperes: 22 Amp
Angle Shear Max Capacity 3/8": 5 x 5
Angle Shear Work Height: 43-1/2"
Coper Notcher Max Capacity: 2-1/2" x 5" x 3/8"
Coper Notcher Work Height: 39-1/2"
Flat Bar Shear Max Capacity 1/2": 14
Flat Bar Shear Max Capacity 3/8": 24
Flat Bar Shear Max Capacity: 3/8" x 24" 1/2 x 14"1x4
Flat Bar Shear Max Round Capacity: 1"
Flat Bar Shear Max Round: 1"
Flat Bar Shear Max Square: 1"
Flat Bar Shear Rating: 65 Tons
Flat Bar Shear Work Height: 34-1/2"
Hydraulic Pump: 10-1/2 gpm
Hydraulic Reservoir: 17 gal
Hydraulics: 3500 psi
Motor Amps: 22 Amp
Horsepower Motor: 7.5 hp
Motor Speed: 1765 rpm
Overall Dimensions (L x W x H): 45" x 62"-1/8 x 57"
Punch Max Capacity: 1-1/16 diam. in 3/4 mild steel
Punch Open Height: 8-3/4"
Punch Rating: 65 Tons
Punch Shut Height: 6-15/16"
Punch Stroke: 1-13/16"
Punch Work Height: 36-9/16"
Rating: 65 Tons
Reservoir: 17 Gal
Valve Pressure: 3500 psi
