| Swing | 43" | 1,092.2 mm |
| Machining Length | 120" | 3,048 mm |
| Chuck Size | 24" | 609.6 mm |
| Power | 50 hp | 37.3 kW |
| Max RPM | 1,500 RPM | 1,500 RPM |
| Turning Dia | 26.57" | 674.88 mm |
| Tailstock | Yes | Yes |
| Control | CNC (Fanuc 0iTD) | CNC (Fanuc 0iTD) |
SWING OVER BED.............. 43"
SWING OVER CROSS SLIDE ..... 26"
MAXIMUM TURNING LENGHT ..... 157"
X-AXIS TRAVEL .............. 26"
Z-AXIS TRAVEL .............. 158"
SPINDLE SPEEDS ............. 20 TO 1200 RPM
SPINDLE BORE ............... 4.13"
SPINDLE NOSE ............... A2-11
SPINDLE DRIVE .............. 45 / 37 KW (60 / 49 HP)
Quill Diameter ............. 5.91"
Quill Stroke ............... 7.887"
Quill Taper ................ #6 MT
RETROFITTED ................ 2018, NEW ELECTRICAL & FANUC CONTROL
CONTROL .................... FANUC 0iTD CNC
HYDRAULIC CHUCK ............ 4-JAW
CHIP CONVEYOR
COOLANT SYSTEM
LUBRICATION SYSTEM
TOOL POST
