NEW KMT SAW CT350 A-NC NM
Overview
Description
KMT SAW CT350 A-NC NM Automatic Non Miter High Speed Circular Saw has a 14" blade size. The CT 350 A-NC family is high speed circular sawing machines designed for high production rates of aluminum extrusions, small aluminum solids, and other non-ferrous materials. A carbide tipped sawblade and spray mist coolant routinely yield rms 50 quality cuts. Double vising provides safety and quality.
Specifications
| Max Blade Diameter | 350 mm | 13.78" |
|---|---|---|
| Round at 0° | 4.5 in. | 4.5 in. |
| Square at 0° | 4.5 in. | 4.5 in. |
| Motor | 3 HP | 3 HP |
| Power | 208v/3, 220v/3, 460v/3 (specify) | 208v/3, 220v/3, 460v/3 (specify) |
| Spindle RPM | 3600 | 3600 |
| Spindle Diameter | 32 mm | |
| Material Work Height | 39.75" | 1,009.6 mm |
| Floor Footprint | 98 w x 52 L in. | 98 w x 52 L in. |
| Shipping Weight | 1,600 lb | 725.7 kg |
| Weight | 1,600 lbs. | 1,600 lbs. |
Capacities shown are max envelope. Each individual cutting job must be considered with regards to type and shape of material, and quantity of pieces per day.
Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 1 YEAR – Parts
Equipped With
Optional Items - Call for price:
AC200: 5' x 15" wide freestanding conveyor (additional 5' sections can bolt together)
AC102: 6' Worktable conveyor infeed/outfeed mounted to machine w/ coolant tray
AC103: Additional 6' connecting to AC102
AC132: Chip Vac
