| Capacity (ga) Mild Steel | 14 gauge | 14 gauge |
| Capacity (ga) Stainless Steel | 18 gauge | 18 gauge |
| Bending Length (inches) | 120" | 3,048 mm |
| Bending Length (feet) | 10' | 3,048 mm |
| Bending Angle | 0-135° | 0-135° |
| Beam Adjustment, Front and Back | 1" | 25.4 mm |
| Minimum Reverse Bend | 0.3125" | 7.9375 mm |
| Machining Length | 146" | 3,708.4 mm |
| Machine Width | 34" | 863.6 mm |
| Machine Height | 44" | 1,117.6 mm |
| Net Weight | 4,000 lb | 1,814.4 kg |
| Dimensions | 146 x 34 x 44 in. | 146 x 34 x 44 in. |
| Weight | 4000 lbs. | 4000 lbs. |
Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 1 YEAR – Parts
Optional Items - Call for price:
24" manual back gauge with slide and lock for all manual brakes
32" single axis, NC programmable power brake gauge with Germany ELGO# P8511
