NEW BETENBENDER 12-70
USD $72,600.00
Overview
Description
** FREE SHIPPING TO COMMERCIAL ADDRESS THAT CAN OFFLOAD**
SHIPPING IS TO LOWER 48 STATES ONLY. OTHER AREAS PLEASE EMAIL FOR FREIGHT QUOTES.
BETENBENDER’S 12-70 press brake's direct acting hydraulic cylinders are one piece, double acting with self-aligning, hardened ball sockets. The electrical systems meet NFPA 79 standards. All machines have disconnect switches, magnetic starters, 110/120v controls, 208-230/460v 3 phase, others optional. Our American made motors are rated for continuous duty, open drip.
Specifications
| Type | HYDRAULIC | HYDRAULIC |
|---|---|---|
| Pressure Tonnage | 70 T | 63,503 kg |
| Distance Between Housings | 126.5" | 3,213.1 mm |
| Table Length | 12' | 3,657.6 mm |
| Overall Length | 159" | 4,038.6 mm |
| Throat depth | 8" | 203.2 mm |
| Rapid Approach | 44 in/min. | 1,117.6 mm/min. |
| Return Speed | 63 in/min. | 1,600.2 mm/min. |
| Pressing Speed | 0-44 IPM | 0-44 IPM |
| Open Height | 14" | 355.6 mm |
| Closed Height | 6" | 152.4 mm |
| Bed Height | 28" | 711.2 mm |
| Bed Width | 4" | 101.6 mm |
| Motor | 10 HP 208/230v, 28amps; 460v, 14amps | 10 HP 208/230v, 28amps; 460v, 14amps |
| 2-Speed Electric Shift | Std. | Std. |
| Width of Upper End Plates | 36" | 914.4 mm |
| Width of Upper Machined Ram | 1.75" | 44.45 mm |
| Width of Upper Ram | 2" | 50.8 mm |
| Overall Height (approx.) | 96" | 2,438.4 mm |
| Overall Width | 45" | 1,143 mm |
| Weight | 15,500 lbs. | 15,500 lbs. |
