| Capacity (ga) Mild Steel | 12 gauge | 12 gauge |
| Capacity (ga) Stainless Steel | 16 gauge | 16 gauge |
| Bending Length (inches) | 48" | 1,219.2 mm |
| Bending Angle | 0-135° | 0-135° |
| Beam Adjustment, Front and Back | 1" | 25.4 mm |
| Minimum Reverse Bend | 0.3125" | 7.9375 mm |
| Machining Length | 71" | 1,803.4 mm |
| Machine Width | 34" | 863.6 mm |
| Machine Height | 44" | 1,117.6 mm |
| Net Weight | 2,300 lb | 1,043.3 kg |
| Dimensions | 71 x 34 x 44 in. | 71 x 34 x 44 in. |
| Weight | 2300 lbs. | 2300 lbs. |
Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 1 YEAR – Parts
Optional Items - Call for price:
24" manual back gauge with slide and lock for all manual brakes
32" single axis, NC programmable power brake gauge with Germany ELGO# P8511
